Description
Parameter Teknis / Technical Parameters
| Parameter | Technical Parameter | Nilai / Value |
|---|---|---|
| Output sinyal pada kapasitas | Signal Output at Capacity | 1.3 ~ 1.5 mV/V |
| Beban layanan | Service Load | 100% Capacity |
| Kesalahan linearitas | Linearity Error | < 0.500% FSO |
| Beban aman | Safe Load | 150% Capacity |
| Non-ulang (repeatability) | Non-Repeatability | < 0.050% FSO |
| Beban samping aman | Safe Side Load | 100% Capacity |
| Gabungan kesalahan | Combined Error | < 1.000% FSO |
| Beban maksimum | Ultimate Load | 300% Capacity |
| Histeresis | Hysteresis | < 0.100% FSO |
| Resistansi input | Input Resistance | 800 ± 50 Ω |
| Kerekan (30 menit) | Creep (30 mins) | < 0.100% FSO |
| Resistansi output | Output Resistance | 705 ± 5 Ω |
| Keseimbangan nol | Zero Balance | < 1% Capacity |
| Resistansi isolasi | Insulation Resistance | > 5000 MΩ @50 VDC |
| Pengaruh suhu terhadap span /10°C | Temperature Effect on Span (/10°C) | < 0.030% FSO |
| Tegangan eksitasi yang disarankan | Excitation Voltage (Recommended) | 5 ~ 20 V AC/DC |
| Pengaruh suhu terhadap nol /10°C | Temperature Effect on Zero (/10°C) | < 0.070% FSO |
| Tegangan eksitasi maksimum | Excitation Voltage (Maximum) | 25 V AC/DC |
| Rentang suhu kerja | Operating Temperature Range | –20 ~ 60°C |
| Rentang suhu penyimpanan | Storage Temperature Range | –50 ~ 85°C |
| Jenis konektor kabel | Cable Connector | M12 male 4 pole (screw type) |
| Bahan | Material | Stainless Steel 17-4PH |
