Description
Specifications & Standards
| Permissible overload | 150 %RC |
|---|---|
| Rated power | 1 mV/V±1% |
| Linearity | 1 %RO |
| hysteresis | 1 %RO |
| Repeatability | 0.3 %RO |
| Recommended applied voltage | Up to 10 V |
| Permissible applied voltage | 15 V |
| Input Resistance | 350 Ω |
| Output Resistance | 350 Ω |
| Temperature Compensation Range | -10～60 ℃ |
| Permissible temperature range | -20～80 ℃ |
| Temperature effect at zero point | 0.01 %RO/℃ |
| Temperature effect on output | 0.01 %/℃ |
| cable | Φ6 mm – 4-core shielded cable 0.5 m with connector at the end |
| connector | Jack / PRC03-32A10-7F |
| Cables Included | L-A-5, see connector types and connections |
