| Spesifikasi | Specification | Nilai / Value |
|---|---|---|
| Tegangan Pecah | Breakdown Voltage | 90V ± 20% |
| Tegangan Pulih | Recovery Voltage | 60V |
| Arus Puncak | Peak Current | 5000A |
| Resistansi Isolasi | Insulation Resistance | 10,000 MΩ |
| Waktu Respons | Response Time | < 0.2μS |
| Penutup | Enclosure | Polycarbonate |
| Berat Bersih | Net Weight | 0.175 kg |
Characteristics and Applications
PT100SA telah dirancang khusus untuk bekerja dengan semua sel beban dan indikator dalam rangkaian PT. Ditempatkan dalam wadah polikarbonat yang kuat dan disegel melalui paking elastomer, PT100SA adalah pilihan untuk perlindungan dari berbagai lonjakan daya yang disebabkan.
The PT100SA has been specially designed to work with all the load cells and indicators in the PT range. Housed in a tough polycarbonate enclosure and sealed via an elastomer gasket, the PT100SA is the choice for protection from various induced power surges.
| Spesifikasi | Specification | Nilai / Value |
|---|---|---|
| Tegangan Pecah | Breakdown Voltage | 90V ± 20% |
| Tegangan Pulih | Recovery Voltage | 60V |
| Arus Puncak | Peak Current | 5000A |
| Resistansi Isolasi | Insulation Resistance | 10,000 MΩ |
| Waktu Respons | Response Time | < 0.2μS |
| Penutup | Enclosure | Polycarbonate |
| Berat Bersih | Net Weight | 0.175 kg |
