Description
Parameter Teknis / Technical Parameters
| Parameter | Technical Parameter | Nilai / Value |
|---|---|---|
| Sensitivitas | Sensitivity | 2.0 Ā± 0.2mV/V |
| Tingkat Akurasi | Accuracy class | C2 / C3 |
| Keseimbangan Nol | Zero balance | Ā±2%F.S |
| Nonlinearitas | Nonlinearity | Ā± 0.02%F.S |
| Histeresis | Hysteresis | Ā± 0.02%F.S |
| Repeatabilitas | Repeatability | Ā± 0.02%F.S |
| Kerekan (30 menit) | Creep(30minutes) | Ā± 0.02%F.S |
| Pengaruh suhu terhadap titik nol | Temperature effect on zero | Ā± 0.017%F.S/10Ā°C |
| Pengaruh suhu terhadap output | Temperature effect on sensitivity | Ā± 0.017%F.S/10Ā°C |
| Impedansi input (Ī©) | Input impedance | 780 Ā± 5 |
| Impedansi output (Ī©) | Output impedance | 700 Ā± 3 |
| Resistansi isolasi | Insulation impedance | ā„ 5000MĪ© (50VDC) |
| Rentang kompensasi suhu | Compensated Temperature Range | ā10Ā°C ~ +40Ā°C |
| Rentang suhu kerja | Operating Temperature Range | ā30Ā°C ~ +70Ā°C |
| Kemampuan beban lebih aman | Safe Overload | 150%F.S |
| Rentang beban lebih batas | Ultimate Overload | 200%F.S |
| Tegangan eksitasi yang disarankan | Excitation, recommended | 10ā15V |
| Tegangan eksitasi maksimum | Excitation, maximum | 18V |
| Ukuran mejig yang disarankan | Platform size | 500 Ć 500mm |
| Kabel penghubung | Cable | ā5.6 Ć 6m |
Kode Warna Kabel / Cable Color Code
- Input +: Merah / Red
- Input ā: Hitam / Black
- Output +: Hijau / Green
- Output ā: Putih / White
