| Beban terukur (Rated Load) |
50kg, 100kg, 150kg, 200kg, 500kg |
| Output terukur (Rated Output) |
2.0000 ± 0.01mV/V |
| Kesalahan keseluruhan (Total Error) |
± 0.02%F.S |
| Kerekan (30 menit) (Creep (30 minutes)) |
± 0.02%F.S |
| Tegangan kerja yang disarankan (Recommended Excitation Voltage) |
5V–18V (AC or DC) |
| Tegangan kerja maksimum (Maximum Excitation Voltage) |
24V (AC or DC) |
| Impedansi input (Ω) (Input Impedance) |
385 ± 5 |
| Impedansi output (Ω) (Output Impedance) |
350 ± 2 |
| Resistansi isolasi(Insulation Impedance) |
≥ 5000MΩ |
| Tingkat kelebihan beban yang aman(Safe Overload) |
150%F.S |
| Tingkat kelebihan beban batas(Ultimate Overload) |
200%F.S |
| Rentang suhu kerja(Operating Temperature Range) |
–30 ~ +70 °C |
| Pengaruh suhu terhadap output(Temperature Effect On Load) |
± 0.02%F.S / 10°C |
| Pengaruh suhu terhadap titik nol(Temperature Effect On Zero) |
± 0.02%F.S / 10°C |
| Bahan(Construction) |
Baja paduan / Baja tahan karat (Alloy/Stainless Steel) |
| Tingkat perlindungan(Protection Class) |
IP68 & IP67 |
| Standar yang dirujuk(Citation) |
GB/T7551–2008 / OIML R60 |
| Panjang kabel(Cable Length) |
⌀6.6mm × 3m |
