Rated Output (R.O.) (mV/V): 2.0 ± 0.005
Zero Balance (mV/V): 0.0 ± 0.020
Accuracy Class:
D3
C3
Non-linearity (% R.O.): ≤ 0.03 (D3), ≤ 0.02 (C3)
Hysteresis (% R.O.): ≤ 0.03 (D3), ≤ 0.02 (C3)
Combined Error (% R.O.): ≤ 0.03 (D3), ≤ 0.02 (C3)
Repeatability (% R.O.): ≤ 0.02 (D3), ≤ 0.01 (C3)
Creep for 30min (% R.O.): ≤ 0.03 (D3), ≤ 0.017 (C3)
Return for 30min (% R.O.): ≤ 0.03 (D3), ≤ 0.017 (C3)
Resolution (mV/V):
≤ 1/3000: 0.00067 (D3)
≤ 1/5000: 0.0004 (C3)
Temperature Effect on:
Zero Value (%/10°C): ≤ 0.03 (D3), ≤ 0.014 (C3)
Output Value (%/10°C): ≤ 0.03 (D3), ≤ 0.011 (C3)
Excitation:
Recommended Voltage (V): 10
Maximum Voltage (V): 15
Resistance:
Input (Ω): 350 ± 3.5
Output (Ω): 350 ± 3.5
Insulation Resistance (MΩ): >2000
Compensated Temperature Range (°C): -10 to +40
Operating Temperature Range (°C): -40 to +70
Material & Plate: Stainless Steel
Cable Specification:
Ø8 x 4P x 10M & Ø8 x 4P x 25M (PVC)
Ø8 x 6P x 12M (Urethane)
Platform Size: Ø8 x 6P x 12M
Safety Overload (% R.L.): 150%
